- Base Mount
3/8″-16 Female - Dimensions
3.74″ / 9.5 cm - Weight
2 lb / 0.9 kg - Drag Control
Fixed
- 15.4 lb Capacity Fluid Head
- Spring-Loaded 8.8 lb Counterbalance
- Continuously Adjustable Pan/Tilt Drag
- Two-Stage Aluminum Photo Tripod
- Height Range of 27.5 to 72″
- Quick Power Leg Locks
General
- Load Capacity : 19.8 lb / 9 kg
- Maximum Working Height : 66.9″ / 169.9 cm
- Max Height without Center Column : 55.1″ / 140 cm
- Minimum Working Height : 3.5″ / 8.9 cm
- Folded Length : 24″ / 61 cm
- Head Mount Type : 3/8″-16 Screw
- Weight : 5.5 lb / 2.5 kg
- Materials : Aluminum Alloy
- Bubble Level : Rotating
- Load Capacity : • Static: 15.43 lb / 7.0 kg• Counterbalance supports 8.8 lb / 4 kg
- Head to Tripod Mounting Thread : 3/8″-16 thread
- Counter Balance System : Spring-loaded
- Counter Balance Range : One fixed spring for 8.8 lb (4 kg) camera weight
- Center of Gravity : Not specified by manufacturer
- Quick Release/Wedge Plate : 504PLONG plate with 1/4″-20 screw and 1/4″-20 to 3/8″-16 adapter
- Balance Plate : 504PLONG plate slides 3.27″ (83.0 mm)
- Tilt Drag : Continuously adjustable from 0 to max level
- Tilt Range : -80° to +90° tilt range front to back
- Tilt Lock : Yes
- Spring Loaded Counter Balance : Yes
- Pan Drag : Continuously adjustable from 0 to max level
- Pan Range : 360°
- Pan Lock : Yes
- Pan Bar • 1 included• 2 possible positions
- Leveling Bubble/Illuminated : Yes/ not specified by manufacturer
- Material : Aluminum
- Color : Black
- Temperature Range : -4 to 104 °F (-20 to 40 °C)
- Height : 5.12 in (13.0 cm)
- Weight : 3.53 lb (1.6 kg)
Center Column
- Center Column Sections : 1
- Center Column Extension Type : Rapid
- Lateral / 90-Degree Center Column : Yes
